Single Girder Hot Crane
Single girder Crane. The main beam of single-girder crane bridge mostly adopts I-shaped steel or a combined section of steel profile and steel plate. Lifting trolleys are often assembled with hand chain hoists, electric hoists or hoists as lifting mechanism components.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
10 ton Single Girder Crane
10 ton Single Girder Hot Crane is widely used in the transfer, assembly, inspection and loading and unloading of industrial and mining enterprises, warehouses, machining workshops, auxiliary workshops of metallurgical plants, stockyards, power stations, etc., and can also replace ordinary double-girder bridge cranes for light Production workshops in the textile industry and instrument industry, etc., where the frequency of use is low or the number of times the rated lifting capacity is lifted is small.
According to a large number of market surveys, we know that the price of 10 ton single cranes in the market generally ranges from several thousand to tens of thousands. It is affected by product design, material, function, model and other factors, and there is no specific price. If you want to know more about the price information of bridge crane, Henan Dejun Lifting recommends that you communicate and consult with us.
|
Lifting Weight(t) |
1 |
2 |
3 |
5 |
10 |
16 |
Customized |
|||||||||||||||||||||
|
Span(m) |
7.5 |
10 |
15 |
18 |
8 |
13 |
18 |
27 |
7.5 |
12 |
18 |
23 |
8 |
12 |
15 |
18 |
8 |
12 |
15 |
20 |
12 |
19 |
25 |
28 |
Customized |
|||
|
Working Speed |
Ground 20 |
Ground 20 |
Ground20 |
Ground 20 |
Customized |
|||||||||||||||||||||||
|
Hoisting Height(m) |
Customized |
|||||||||||||||||||||||||||
|
Working Class |
A4 or Customized |
|||||||||||||||||||||||||||
|
Electric Current |
Customized |
|||||||||||||||||||||||||||
Application range
It is forbidden to use in the environment of flammable, explosive and corrosive media.
Product Description
1. Designed and manufactured according to the standard JB/T1306-2008, it has the characteristics of reasonable structure and strong rigidity of the whole machine.
2. The whole machine is used together with CD1, MD1, HC and other types of electric hoists.
It has two independently operated electric hoists, which can independently complete the lifting of workpieces, and can cooperate with each other to complete the turning of large workpieces. At the same time, each control handle can independently control the shared cart running mechanism.
3. The lifting capacity is 1+1--16+16 tons, the applicable span is 5-35 meters, the working level: A3, A4, and the working environment is within the range of -25°C~+40°C.
4. The overall transmission adopts a soft drive motor and a reducer to ensure its low noise and stable moving performance.
5. According to the needs of the customer's on-site working conditions, it can be equipped with frequency conversion for the cart, frequency conversion for hoisting or double-speed hoist operation, so that the operation of the crane (crane) is stable and reliable.
