200 Ton Double Beam Gantry Crane With Crane Rectangular Electromagnet

200 ton Double Beam Gantry Crane with Crane Rectangular Electromagnet is the same in structure as the 100 ton electric Double Girder Gantry Crane with Crane Circular Electromagnet. The only difference between the two of them is their spreader. It is an indispensable lifting tool for magnetically conductive materials such as metallurgy, mining, machinery, etc.

It is strictly prohibited to use in flammable, explosive corrosion (acid, alkali, and zinc vapor), high temperature solution, overload, powder and other dangerous operations. The working level can be achieved A5-A8. If you need special environmental work, you can contact us to explain the situation and customize the non-standard design.

2. Parameters:

The lifting height, span, equipped spreader and lifting weight of the crane can be customized. If you have different needs, you can directly consult us.

3. Component:

The components of the 200 ton Double Beam Gantry Crane with Crane Rectangular Electromagnet are the same as those of the 100 ton electric Double Girder Gantry Crane with Crane Circular Electromagnet.

The main beam adopts double main beam rectangular section, the plate is welded into a rectangular section, and the main beam is provided with a diaphragm and an angle steel to prevent the main beam from being unstable. There are rib plates under the laying track, and the track is laid flat on the main beam for the trolley to run; The outrigger adopts box-shaped variable section, and the outrigger and the main beam are connected by flange bolts; In addition to the upper installation of the hoisting mechanism and the trolley running mechanism, Correspondingly, passages, railings, etc. are set up, which ensures that drivers and staff can reach any part of the trolley under any circumstances.

There are hoisting screw holes on both sides of the rectangular electromagnetic chuck, which can be hoisted by screwing in T-shaped screws during installation. Fix it on the worktable with T-blocks and screws, connect the DC power supply and ground wire on the machine tool, then grind the upper surface of the suction cup once to ensure the parallelism of the upper surface to the bottom surface. When the work piece is adsorbed, as long as the two adjacent magnetic poles are overlapped, Sufficient positioning suction can be obtained for grinding. Through the machine button, the magnetization and demagnetization of the work piece can be realized.

4. Applicable Environment:

The use environment of the 200 ton Double Beam Gantry Crane with Crane Rectangular Electromagnet is the same as that of the Electromagnetic Bridge Crane, but it can be used outdoors. If the use environment requires special instructions, we will customize it according to the actual use conditions.

5. How to operate?

6. Transportation:

7. Precautions for use:

(1) There should be no cracks in the electromagnet shell and cover, and the sealing should be reliable, and the excitation coil should not be corroded by water or oxidizing gas.

(2) The operation should be carried out according to the requirements of the power-on duration rate, and the power supply of the lifting electromagnet should be cut off when it is stopped for use or rest.

(3) The hoisting electromagnet can be energized only after it touches the hoisting weight. During the operation, no person, vehicle or operation shall be carried out according to the safety requirements specified in the instruction manual within 2m.

(4) The lifting electromagnet shall not be impacted, and it is strictly forbidden to use it as a heavy hammer.

(5) The lifting electromagnet that is connected to the power supply can be lifted only after the current is fully increased. After lifting off the ground, it should be stopped for a short period of time, and only when it is confirmed that there is no gap between the hoisting weight and the electromagnet, there is no foreign matter, and that the hoisting weight has been firmly absorbed, the hoisting and hoisting can be continued.

(6) For battery-type lifting electromagnets, the ventilation holes on the wet-type battery shell shall not be blocked to prevent gas accumulation.

(7) Electromagnets for general purposes shall not be used in the medium where there is a danger of explosion, the altitude exceeds 2000m or the concentration is sufficient to corrode metals and damage insulation.
