5 Ton Suspension Single Beam Overhead Crane with Electric Wire Rope Hoist
5 ton Suspension Single Beam Overhead Crane with Electric Hoist is composed of the main beam, end beam, electric wire rope hoist and electric trolley welded by steel plate and I-beam.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
1. Product Introduction:
5 ton Suspension Single Beam Overhead Crane is composed of the main beam, end beam, electric wire rope hoist and electric trolley welded by steel plate and I-beam.
It hangs on the I-beam track in the upper part of the workshop, and the electric hoist runs along the lower flange of the I-beam of the main beam to complete the lifting and transportation of items.
The working environment temperature is -20-+40 ℃, which is widely used in production workshops, warehouses and freight yards and other places. It is forbidden to work in the environment of flammable, explosive and corrosive media. The working class is A3~A4.
2. Parameters:
| Model | LX0.5-S | LX1-S | LX2-S | LX3-S | LX5-S | LX10-S | ||||||
Lifting Weight(t) | 0.5 | 1 | 2 | 3 | 5 | 10 | ||||||
Span(m) | Customized | |||||||||||
Working Speed | 20 30 | 20 30 | 20 30 | 20 30 | 20 30 | 20 30 | ||||||
Model of Electric Hoist | CD1 | MD1 | CD1 | MD1 | CD1 | MD1 | CD1 | MD1 | CD1 | MD1 | CD1 | MD1 |
Hoisting Height(m) | 6 9 12 18 | 6 9 12 18 | 6 9 12 18 | 6 9 12 18 | 6 9 12 18 | 6 9 12 18 | ||||||
Lifting Speed(m/min) | 8 | 8/0.8 | 8 | 8/0.8 | 8 | 8/0.8 | 8 | 8/0.8 | 8 | 8/0.8 | 7 | 7/0.7 |
Working Class | A3-A4 | |||||||||||
Electric Current | Customized | |||||||||||
3. Component:
5 ton Suspension Single Beam Overhead Crane is composed of metal structure, lifting mechanism, running mechanism and electrical parts.
Metal structure part: The main beam is made of U-shaped channel steel formed by steel plate rolling, and welded with I-beam to form a box-shaped solid web beam. The end beam is composed of channel steel, and the main and end beams are hinged with pins to ensure that the wheels can contact the track in a balanced and effective manner, and it is convenient for disassembly, transportation and storage.
Lifting mechanism: The electric wire rope hoist is used as the hoisting mechanism.
Running mechanism: The crane operating mechanism adopts the electric trolley structure for electric hoist, which is driven by a conical rotor motor, and the running speed can be customized according to customer requirements.
Electrical part: There are two types of crane power supply introduction forms: safety sliding contact line and flexible cable power supply. The electric wire rope hoist and the whole crane are equipped with safety devices. Such as: lifting limit switch, end limit switch, overload limiter, etc., and equipped with power cutoff and phase-misalignment protection devices.
4. Applicable Environment:
5 ton Suspension Single Beam Overhead Crane with Electric Hoist is a general purpose crane, which is mostly used in machinery manufacturing and assembly, warehouses, sewage treatment plants, concrete workshops, caves and other places.
Not suitable for fire hazard, explosion hazard media and places with relative humidity greater than 85% or full of corrosive gases, It is also not suitable for lifting molten metal and toxic, flammable and explosive items.
5. Advantages:
① Precision and Control
Our crane is designed with precision and control in mind. The electric wire rope hoist provides smooth and easy lifting, while the suspension system ensures stability and safety throughout the lifting process. With up to 5 tons of lifting capacity, this crane can handle heavy loads without any issues.
② Durability and Reliability
Our 5 Ton Suspension Overhead Crane is built to last. Constructed from high-quality materials and manufactured with attention to detail, this crane is designed to withstand the rigors of even the toughest industrial environments. You can rely on it to perform day in and day out, no matter what your business throws its way.
③ Easy Installation and Maintenance
Our crane is easy to install and maintain, making it a great choice for businesses of all sizes. We provide detailed installation instructions and offer technical support to ensure that your crane is up and running quickly and efficiently. Additionally, our crane requires minimal maintenance, which means less downtime and more productivity for your business.
④ Affordability
While our 5 Ton Suspension Single Beam Overhead Crane with Electric Wire Rope Hoist offers superior quality and features, it is also affordable. We understand that businesses need to make the most of their budgets, and we are committed to offering high-quality products at an affordable price point. You can get the performance and reliability you need without breaking the bank.
6. Why choose us?
Punctual delivery time.
Professional overseas installation & training team.
Provide one-stop solution
