5 Ton Single Girder Overhead Gantry Crane with European Chain Hoist
5 ton Single Girder Overhead Gantry Crane with European Chain Hoist is an important item handling equipment in the production workshop, stockyard, power station workshop and warehouse to realize the mechanization and automation of the production process, reduce manual labor and improve production efficiency.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
1. Product Introduction:
5 ton Single Girder Overhead Gantry Crane with European Chain Hoist is an important item handling equipment in the production workshop, stockyard, power station workshop and warehouse to realize the mechanization and automation of the production process, reduce manual labor and improve production efficiency.
Different from the traditional single girder bridge crane with electric chain hoist, the working class of the European Style Electric Chain Hoist is higher than that of the ordinary electric chain hoist during the working process, so the European Style Electric Chain Hoist work more efficiently. The working level can reach A5-A6.
2. Parameters:
| Lifting Weight(t) | 1 | 2 | 3 | 5 | 10 | 16 | Customized | ||||||||||||||||||
Span(m) | 7.5 | 10 | 15 | 18 | 8 | 13 | 18 | 27 | 7.5 | 12 | 18 | 23 | 8 | 12 | 15 | 18 | 8 | 12 | 15 | 20 | 12 | 19 | 25 | 28 | Customized |
Working Speed | Ground 20 | Ground 20 | Ground 20 | Ground 20 | Customized | ||||||||||||||||||||
Hoisting Height(m) | Customized | ||||||||||||||||||||||||
Working Class | A4 or Customized | ||||||||||||||||||||||||
Electric Current | Customized | ||||||||||||||||||||||||
3. Component:
The Single Girder Overhead Crane With Electric European Chain Hoist consists of a main girder, two end beams, a cart operating mechanism, a European Style Chain Electric Hoist, and an electrical control system;
The bridge frame of the Single Girder Overhead Crane with Electric European Chain Hoist is composed of a main beam and two end beams. It supports the self-weight and hoisting load of the whole crane, and is also the body of the crane cart. On the platforms on both sides of the crane, the cart operating mechanism and electrical equipment are installed.
The main beam is I-beam. Due to the large load, vertical and horizontal auxiliary trusses are added to the I-beam. The strength and rigidity of the main beam have been strengthened.
The end beam is usually composed of a pair of opposite channel steel, and the traveling wheel is installed in the end beam. The lifting structure is a European style electric chain hoist, which is hung on a small frame that can walk along the lower flange of the I-beam.
The car operating mechanism of the crane generally adopts centralized drive, and the car operation adopts electric drive.
The sprocket design of the hoisting mechanism (European-style electric chain hoist) is compact, and there is no need to disassemble the motor or gearbox parts. The professional sprocket design makes the machine run more smoothly, the chain wear is smaller, and the equipment maintenance is more convenient. At the same time, the length of the cable can be adjusted by itself. Adjustment, high safety factor, standard two-speed motor.
4. Applicable Environment:
Single Girder Overhead Crane are widely used in workshops, factories, warehouses, stockyards, industrial and mining enterprises, iron and steel chemicals, railway transportation, ports and other occasions to lift goods.
5. Wearing Parts:
The wearing parts of Single Girder Overhead Crane with Electric European Chain Hoist include travel limiters, slings, and current collectors.
6. European crane performance
Compared with traditional industrial cranes, European Overhead Gantry Crane has excellent performance in the following aspects:
Light dead weight: The 5 ton European Overhead Gantry Crane is made of high-quality materials and advanced technology. It adopts the most reasonable structural design from the trolley to the main beam, making its dead weight far lower than traditional cranes.
Low energy consumption: European Single Girder Overhead Gantry Crane adopts variable frequency speed regulation technology and intelligent control system, which can adjust speed and power according to different working conditions to achieve energy saving and consumption reduction.
Environmentally friendly and pollution-free: European Overhead Gantry Crane adopts noiseless drive and wear-free brake, which will not produce noise and dust pollution during operation.
Intelligent and efficient: European Overhead Gantry Crane adopts advanced intelligent control system and sensor technology, which can realize wireless remote control, automatic positioning, overload protection and other functions, and is connected to the computer network for remote monitoring and management.
7. Transportation:
Shipping way: by sea, air, land, and Express such as DHL, TNT, UPS, FedEx. We will choose the suitable shipping method according to your requirements.
8. Why choose us?
Focus on crane customization.
Exports to more than 120 countries.
Provide one-stop solution.
