Mini Electric Trolley Type Lift Electric Wire Rope Cable Hoist With Remote Control
Mini Electric Trolley Type lift Electric Wire Rope cable Hoist with remote control is also called civil electric hoist. Generally divided into fixed type and running type, it is suitable for various occasions and can lift goods under 1000 kg, especially suitable for lifting heavier items from downstairs in high-rise buildings.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Mini Electric Trolley Type lift Electric Wire Rope cable Hoist with remote control is also called civil electric hoist. Generally divided into fixed type and running type, it is suitable for various occasions and can lift goods under 1000 kg, especially suitable for lifting heavier items from downstairs in high-rise buildings.
The Mini Electric Trolley Type lift Electric Wire Rope cable Hoist has reached international standards in terms of production and design, which ensures the safety of use. The motor heat sink adopts cast iron structure, which improves the service life.
The lifting speed of the Mini Electric Trolley Type lift Electric Wire Rope cable Hoist can reach 10m/min. The length of the wire rope is initially designed to be 12m (the length can be customized). In terms of hooks, an advanced double hook setting is specially designed, which greatly increases the lifting weight of the miniature electric hoist. .
Micro electric hoists generally use 220V civilian power supply, and can also be customized, especially suitable for daily civilian use, industrial production lines, freight logistics and other occasions.
2. Parameters:
Model | HGS-B100/200 | HGS-B125/250 | HGS-B150/300 | HGS-B200/400 | HGS-B250/500 | HGS-B300/600 | HGS-B400/800 | HGS-B500/1000 |
Voltage(V) | 220/230 | 220/230 | 220/230 | 220/230 | 220/230 | 220/230 | 220/230 | 220/230 |
Power(kw) | 510 | 510 | 600 | 980 | 1020 | 1200 | 1300 | 1600 |
Capacity(T) | 100/200 | 125/250 | 150/300 | 200/400 | 250/500 | 300/600 | 400/800 | 500/1000 |
Lifting speed(m/min) | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 | 10/5 |
Lifting height(m) | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 | 12/6 |
Packing size(cm) | 47×37×16 | 47×37×16 | 47×37×16 | 52×45×17.5 | 52×45×17.5 | 52×45×17.5 | 52×45×17.5 | 51.5×34×19 |
G.W. / N.W.(kg) | 24/22 | 25/23 | 26/24 | 35/33 | 36/34 | 35/33 | 39/37 | 33.7/32.7 |
3. Component:
As a new type of electric hoist, Mini Electric Trolley Type lift Electric Wire Rope cable Hoist with remote control is widely used in production lines, assembly lines, assembly machines, logistics transportation and other occasions in modern industries such as machinery manufacturing, electronics, automobiles, shipbuilding, work piece assembly and high-tech industrial zones.
It can better show its excellent quality when working in warehouses, docks, ingredients, hanging baskets and work sites with narrow spaces. It is the best supporting product for fixed-column and wall-type jib cranes.
The Mini Electric Trolley Type lift Electric Wire Rope cable Hoist with remote control has beautiful appearance, reasonable structure, convenient installation, low noise, safe and reliable use, so Mini Electric Trolley Type lift Electric Wire Rope cable Hoist is widely used in factories, workshops, homes, warehouses, restaurants, shopping malls, decoration and handling.
4. How to install
(1) Open the box. Be sure to lift the tape wrapped around the drum wire rope, and take it off before you can test the machine. If you try the machine in a hurry, it may cause the wire rope to reverse and damage the limit frame.
(2) The direct contact between the wire rope and the limit frame should be avoided, otherwise the limit switch will fail and the miniature electric hoist will not work normally.
(3) Do not let the miniature electric hoist be drenched in rain or soaked in water. The protection level of the miniature electric hoist is IP54.
(4) The body of the miniature electric hoist cannot be moved or rotated along the installation rod.
(5) The standard power supply for the miniature electric hoist is single-phase alternating current, and a socket with a ground wire must be used.
(6) Warning: Make sure that all cables keep a proper distance from the rotating or heating parts on the miniature electric hoist.
(7) The electric hoist is in the state of not lowering, and the last three circles of wire rope painted with red paint on the electric hoist drum cannot be released. If you continue to press the lowering switch, the wire rope will be reversed around the upper rope drum, which will reverse the upward and downward operation of the electric hoist, so that the limit switch will lose its function.
5. How to operate?
7. Use precautions
(1) Please read the instruction manual carefully before using the Mini Electric Trolley Type lift Electric Wire Rope cable Hoist.
(2) The installation position of the Mini Electric Trolley Type lift Electric Wire Rope cable Hoist must be selected in an occasion that meets the needs and is easy to operate.
(3) Regularly check whether the installation of the hoist is firm.
(4) Please do not overload or use the hoist when you do not know the weight of the hoisting object.
(5) When hoisting, do not pull or hoist heavy objects diagonally to avoid danger.
(6) When the hoist lifts heavy objects, it is strictly forbidden for anyone to stand under the heavy objects.
(7) When operating the wire rope, please wear thick gloves, and please do not let the wire rope slip through your hands, so as to avoid slippage or puncture.
(8) The hoist shall not carry people in any way, or be used as an elevator hoisting tool.
(9) The operator should not operate the hoist under the condition of drinking, taking medicine or being ill.
(10) Please do not modify or weld the parts of the hoist at will.
(11) When the hoist is hoisting, be sure to keep at least 3 turns of wire rope on the rope drum to prevent the wire rope from falling off the rope drum due to excessive force.
