Single Girder Semi Mobile Gantry Crane with Single Winch Trolley
The main beam of the Single Girder Semi Gantry Crane With Single Winch Trolley has outriggers at one end, which can walk directly on the track on the ground, and the other end is the end beam, which walks on the track of the load-bearing beam on the pillar of the workshop, and is mostly used for loading and unloading in open spaces and warehouses or Grab materials, generally using ground line operation or remote control operation.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
1. Product Introduction:
The main beam of the Single Girder Semi Gantry Crane With Single Winch Trolley has outriggers at one end, which can walk directly on the track on the ground, and the other end is the end beam, which walks on the track of the load-bearing beam on the pillar of the workshop, and is mostly used for loading and unloading in open spaces and warehouses or Grab materials, generally using ground line operation or remote control operation.
Compared with the Single Girder Semi Gantry Crane with Single Winch Trolley, when the electric hoist is used as the hoisting mechanism, the electric hoist runs along the track under the main beam; when the hoisting trolley is used as a hoisting mechanism, it runs on the main beam along the track on the main beam. The work level can reach A5-A6.
2. Parameters:
Span | m | 10 | 12 | 16 | 20 |
Lifting Capacity(t) | T | 5 | 10 | 15 | Customized |
Lifting Height | m | 6 | 6 | 6 | 6 |
Lifting Speed | m/min | 8 | 8 | 8 | 8 |
Crane Speed | m/min | 20 | 20 | 20 | 20 |
Trolley Motor | kw | 0.4 | 0.4 | 0.4 | 0.4 |
Max Wheel Load | KN | 14 | 19 | 27 | 35 |
Main Dimension | mm | 10 | 12 | 16 | 20 |
Up Wheel Base | W1 | 2000 | 2000 | 2500 | 3000 |
Hook Left Limitation | S1 | 871 | 871 | 871 | 871 |
Up Leg Distance | L1 | 1400 | 1400 | 1400 | 1400 |
3. Component:
The Single Girder Semi Gantry Crane with Winch is generally composed of a main beam, outriggers, a cart operating mechanism, a winch trolley, an operating handle and a ground beam.
The hoisting trolley acts as the hoisting mechanism of the semi-gantry single-girder crane and runs along the main girder. Its metal structure is composed of main beam and outriggers. The semi-gate main beam and outriggers are welded with steel plates to form a box-type structure, which has the characteristics of high safety and high rigidity.
4. Transportation:
5. Precautions for using Semi Gantry Crane related tools
① Tools used for high-altitude operations should be tied with strong safety ropes.
② The jack is strictly prohibited from being overloaded and the handle must not be lengthened. When used, it should be placed on a stable and solid place and must be perpendicular to the load.
③ The chain hoist lifting chain must not be twisted, split into single strands for use, or overloaded.
④ If the suspended objects of the chain hoist are not used for a long time, the bracelet should be tied to the lifting chain.
⑤ Do not wear gloves when hammering.
⑥ The fulcrum of the pry bar should be firm, and it is strictly forbidden to apply pressure with both hands when using it at high places.
⑦ When using electric or pneumatic tools, ensure the safety performance of the tools and power supply facilities. Testing their safety performance should be conducted on a platform or a relatively spacious and safe place.
6. Why choose us?
7*24h online services.
Almost 35 years production experience in crane industries.
7. Frequently Asked Questions:
How long can we provide design solutions?
Less than 24 hours
Do you have engineer oversea installation service?
Yes; we have;
