Overbridge Crane

10t single girder overbridge crane



1. Product Introduction:



10t single girder overbridge crane is the lifting equipment for lifting materials over the workshop, warehouse and storage yard. It is shaped like a bridge because its two ends are perched on tall cement columns or metal supports. The bridge frame of the bridge crane runs longitudinally along the track laid on both sides of the elevated frame, which can make full use of the space below the bridge to lift materials without being hindered by ground equipment. It is a kind of lifting machinery with a wide range and a large number of uses.



Product name: 10t single girder overbridge crane



Lifting capacity: 3-50 tons



Span: 4-40m



Lifting height: 1-40m



Lifting mechanism: wire rope hoist



Working environment: -25~40



working class: A3-A7



Power supply: 380v50hz3p or according to customer demand



Safety facilities:



1. Overload protection device



2. High quality long time bearing polyurethane material buffer



3. Crane travel limit switch



4. Lower voltage protection function



5. emergency Stop the system



6. Lift the height limit device



2. Parameters:



Lifting Weight(t)	1				2				3				5				10				16				Customized
Span(m)	7.5	10	15	18	8	13	18	27	7.5	12	18	23	8	12	15	18	8	12	15	20	12	19	25	28	Customized
Working Speed (m/min)	Ground 20								Ground 20								Ground20				Ground 20				Customized
Hoisting Height(m) Customized	Customized
Working Class	A4 or Customized
Electric Current	Customized

3. Component:



10t single girder overbridge crane consists of a main beam, two end beams, a cart running mechanism, a wire rope electric hoist, and an electrical control system;



4. Applicable Environment:



10t single girder overbridge crane are widely used in workshops, factories, warehouses, stockyards, industrial and mining enterprises, iron and steel chemicals, railway transportation, ports and other occasions to lift goods.

5. How to operate?

Pendant or wireless remote control



Please Click Here To Know More.



6. What safety technical regulations should lifting wire rope slings comply with?



Basis: Technical Specification for Lifting and Hoisting Safety in Construction Construction JGJ276-2012.



1) The sling can be 6×19, but it is better to use 6×37 type steel wire rope to make a ring type or an 8-strand head type. Its length and diameter should be determined according to the geometric size and weight of the hoisted object and the lifting tools and lifting methods used. Sure. It can be used in single, double, four or multiple suspension forms.



(a) Ring sling



(b)8-strand sling



2) The rope rings or rope sleeves at both ends of the sling should use braided connectors, and the length of the braided connectors should not be less than 20 times the diameter of the wire rope. The rope sleeves at both ends of the 8-strand head sling can be equipped with sling accessories such as peach rings, snap rings or hooks according to work needs.



3) The safety factor of the sling: when using the hook or snap ring on the sling to hang the lifting ring on the heavy object, it should not be less than 6; when using the sling to directly tie the heavy object, and the sling is not in contact with the heavy object When proper protection measures are taken between the edges and corners, the safety factor should be 6 to 8; when lifting heavy, large or precise heavy objects, in addition to taking proper protection measures, the safety factor should be 10.



7. Frequently Asked Questions



(1)What is the warranty period, and how can I claim warranty If my crane have any issue?

Our warranty period is 12 months after cargo leave China port. If the crane have any issue, our after-sales team and engineer will help you solve the issue by email or Video conference.

If the defect is caused by quality issue, we will ship the spare parts to you to help you fixed it as soon as possible.



(2)What's your package?

Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;



(3)Where is Your Factory? May I visit Your Factory?

Xinxiang city, Henan Province. We can pick up you at the train station or airport, and book hotel for your in advance, if you visit our factory.



(4)What does our after-sales service include?

First of all, it is reflected in the installation. Our company has a professional team of engineers to install it for you.

Secondly, it is reflected in our consulting service. When there is a problem with your product, we will provide online Q&A service at any time.

Finally, we will provide corresponding manuals and drawings for the product.

If you have other questions about our after-sales service, please consult our online customer service.
