Lightweight Roof Mounted Gantry Jib Crane With Chain Block Hoist
The wall-type cantilever crane includes a lower rail and an upper rail respectively arranged at the top and the lower part of the column, an end beam is arranged between the lower rail and the upper rail, the bottom and top of the end beam are provided with guide wheels, and the bottom and top of the end beam are provided with guide wheels.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
The wall-type cantilever crane includes a lower rail and an upper rail respectively arranged at the top and the lower part of the column, an end beam is arranged between the lower rail and the upper rail, the bottom and top of the end beam are provided with guide wheels, and the bottom and top of the end beam are provided with guide wheels.
The guide wheels are respectively embedded in the track grooves of the lower track and the upper track, a boom is horizontally arranged on the top of the end beam, and a Chain Block Hoist is suspended at the bottom of the boom, and the working level can reach A3-A4.
2. Parameters:
Lifting weight | t | 1 | 3 | 5 | 10 or Customized | ||||||||
Lifting height | h (m) | 6 | 9 | 12 | 6 | 9 | 12 | 6 | 9 | 12 | 6 | 9 | 12 |
Maximum cantilever | R1 (m) | 5 | 6 | 7 | 5 | 6 | 7 | 5 | 7 | 9 | 5 | 7 | 9 |
Minimum cantilever | R2 (m) | 1 | 1 | 1 | 1.2 | 1.2 | 1.2 | Customized | |||||
Lifting speed | m/min | 8 or Customized | |||||||||||
Trolley speed | m/min | 20 or Customized | |||||||||||
Travelling speed | m/min | 30 or Customized | |||||||||||
3. Component:
Lightweight roof mounted gantry Jib Crane with Chain Block Hoist is composed of three parts: the structural frame, the electrical system, and the Chain Block Hoist.
4. Applicable Environment:
Lightweight roof mounted gantry Jib Crane with Chain Block Hoist is mostly used in conjunction with the beam-type or bridge-type crane above.
It serves a rectangular space near the wall and is responsible for lifting light and small objects. Larger parts are undertaken by the beam-type or bridge-type crane.
5. How to operate?
