Freestanding Overhead Crane

1. Product Introduction:



Eot freestanding overhead crane is a new generation of technological innovation lifting equipment. Freestanding overhead crane has compact structure, wide work range, light dead weight, small dimension, low noise, low impact force and high stability.



2. Parameters:



Lifting Weight(t)		5		10			16/3.2		20/5		32/5			50/10		75/20	100/20
Span(m)		10.5、13.5、16.5		13.5、16.5、19.5			16.5、19.5、22.5		19.5、22.5、25.5		19.5、22.5、28.5			22.5、25.5、28.5		13.5、19.5、28.5	13、16、19
Travelling Speed of Crab(m/min)		37.2		43.8			44.6		44.6		42.4			38.5		38.4	33.86
Travelling Speed of Trolley(m/min)	A5	89.8	91.8	89.8	91.9	84.7	84.7	87.6	84.7	87.6	87.6	74.2	74.6	74.6		65	65.7
	A6	92.7	93.7	92.7	93.7	86.5	76	89	76	89	89	75.3	75.3	75	76.6	66.2	65.7
Working Class		A5-A8
Electric Current		Three-phase AC 380V 50Hz or Customized



3. Component:

Freestanding Overhead Crane are mainly used for handling and translation of slabs in continuous rolling mills. The crane is mainly composed of an electrical system, a trolley, a cart operating mechanism, a bridge frame and a clamp, which is consistent with the general double-girder overhead crane, but the Eot freestanding overhead crane are generally operated in the control room.



The electric slab clamp and the trolley are rigidly connected through the guide cylinder device to prevent the swing, and the guide cylinder device adopts a three-stage telescopic type.



4. Applicable Environment:

Eot overhead crane are suitable for indoor or open-air fixed spans such as steel mills, shipyards, ports, storage yards and warehouses to load, unload and transport steel slabs, profiles and other materials.


The clamping device is the picking device of the Eot freestanding overhead crane, It cooperates with several working mechanisms of the crane to break the soup path from the ingot car, clamp the ingot, put the ingot into the soaking furnace, and then take out the heated ingot from the soaking furnace and send it to the ingot car or directly.


Put it on the stick track and transport it to the blooming mill.


In addition, Eot freestanding bridge crane can also be used to move the ingot car or clamp the upper cleaning rake to clean the furnace bottom.

5. Wearing Parts:

The wearing parts of Eot crane include brake rings, rope guides, buffers, travel limiters, contactors, and current collectors.



6. How to operate a Eot freestanding overhead crane?

Eot freestanding overhead crane has two types of operation on the ground and in the air.


There are two types of ground operation: wired handle operation and wireless remote control operation;


Aerial operation refers to cab operation. There are two types of driver's cab, open type and closed type, which can be divided into two types of left or right installation according to the actual situation.



7.Transportation:

8. Advantages?



① Improved speed control, faster and more accurate loading positioning.



② Increase the operation range of the eot freestanding overhead crane.



③ High transmission efficiency and strong bearing capacity.



④ Compact structure, low noise, no oil leak, long lifetime.



⑤ Light dead weight(reduce 15%-30% wieght)



⑥ Ligh stability



⑦ Low impact force



⑧ Wide work range



9. Frequently Asked Questions about Eot freestanding overhead crane



Q: What’s your MOQ?
A: 1 Set.

Q: What’s your package?
A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes.

Q: What’s your delivery period?
A: Within 10/25/40 days after your final payment received; exact period should be based on detailed requirements and actual period;

Q: What’s your warranty period?
A: within 12 months of receipt of the goods.
