Single Girder Crane Manufacturer

1. Product Introduction:



Single girder crane manufacturer is an excellent option for companies that require a reliable and durable crane capable of handling heavy loads. It is affordable, customizable, and built with the best quality materials, making it an excellent addition to any production line. We invite interested clients to contact us for more information on this excellent product.The Working Class is A3-A4.



2. Parameters:



Lifting Weight(t)	1				2				3				5				10				16				Customized
Span(m)	7.5	10	15	18	8	13	18	27	7.5	12	18	23	8	12	15	18	8	12	15	20	12	19	25	28	Customized
Working Speed (m/min)	Ground 20								Ground 20								Ground20				Ground 20				Customized
Hoisting Height(m) Customized	Customized
Working Class	A4 or Customized
Electric Current	Customized

3. Component:



Single girder crane manufacturer consists of a main beam, two end beams, a cart running mechanism, a wire rope electric hoist, and an electrical control system;



The electrical control system consists of the main engine cart control box, electric hoist control box, overload limiter, break fire limiter, travel switch, remote control, collector, seamless sliding contact line, drop wheel, tow cable, wire drawing, rope buckles, flange bolts and other accessories;



4. Applicable Environment:



Single girder crane manufacturer is widely used in workshops, factories, warehouses, stockyards, industrial and mining enterprises, iron and steel chemicals, railway transportation, ports and other occasions to lift goods.



This type of overhead crane is specially created to cater to a broad range of material-handling needs, and it is widely used in various industries, including construction, manufacturing, and mining.

5. How to operate?



The single-girder crane has two types of operation on the ground



Please Click Here To Know More.



6. The protective devices for mechanical equipment on electric bridge cranes include:



Guardrails at each position: In order to better protect the safety of workers and avoid accidents caused by accidental falls. Guardrails of no less than 1m are provided on both sides of the walkway, end beams and trolleys.



Lifting hook safety card: prevent the galvanized steel wire rope from sliding off the hook when the distance between the two sides of the lifting equipment is relatively large or the bearing capacity is relatively large when lifting items.



Rail top partition: The node partitions on both sides of the operation of the trolley and trolley are to prevent safety accidents caused by overside of the trolley and trolley; the safety sliding line partition of the trolley is to prevent safety accidents caused by the crane's overside caused by the shaking of the lifting hook. .



Hydraulic buffer: It works in conjunction with the node partition (impact block) to reduce the impact force when the trolley and the trolley, and the vehicle and the rail node collision block collide (most hydraulic buffers for lifting equipment are torsion springs) Mode).



Rail sweeper: To prevent dirt on the rails, there are rail sweepers to drag foreign objects to both sides.



Protective cover: Rapidly rotating shaft protective cover, lifting hook protective cover, pulley protective cover, etc. to protect the safety of movable components, ensure the safety of employees, and prevent cast iron parts from being damaged by impact.



Cab fire extinguisher: an indispensable item to prevent circuit fires, usually powder fire extinguishers.
