Powered Gantry Crane

1. Product introduction:



The lifting mechanism of the powered gantry crane is on the lifting trolley, the lifting trolley is composed of a drum, a motor, a reducer, a brake and an electrical appliance, and the lifting trolley runs on the double main beam. Working grade A5 or A6, with durability, long life and other characteristics.



There are two operation modes: air operation and ground operation. It is mainly used for the loading and unloading of outdoor cargo yards, stockyards and bulk cargoes. The working environment is below +40℃, the working level is 25%, and the wind pressure is not more than 125Pa.It is strictly prohibited to use for lifting high temperature molten liquid, inflammable, explosive, corrosive, overloaded, dust and other dangerous operations.

2. Parameters of powered gantry crane:



When purchasing a 40 Ton Travelling Gantry Crane, please provide the following data so that we can confirm your needs faster!



① Lifting weight;



② Span (track center to guide rail center);



③ Lifting height (hook center grounded);



④ Whether external overhang is required (please provide the overhang length);



⑤ Are guide rails and cables required? (please provide run length);



⑥ Other special requirements. If you have more detailed information, please let us know and we will give you a more accurate price!

3. Applicable Environment of powered gantry crane:

4. Wearing Parts of powered gantry crane：



Safety hook, Rope guide, Brake ring



5. Transportation of powered gantry crane:

6. Key elements of human-computer interface of powered gantry crane:



1. Ergonomic design: the shape and key layout of the gantry remote controller should conform to the ergonomic principle, making the operator comfortable to hold, the key operation natural and smooth, reducing the operator's fatigue.



2. Button layout: A reasonable button layout can improve the convenience and accuracy of operation. Commonly used buttons should be placed in a position easily accessible to the operator and distinguished by different shapes and colors to reduce the risk of misoperation.



3. Display design: The display on the gantry remote controller is used to display the status of the crane, fault information, etc., the design should be concise and clear, the font size is moderate, and the backlight brightness can be adjusted so that it can be clearly visible in different lighting environments.



4. Sound and vibration prompts: the gantry remote controller can provide operational feedback through sound and vibration, such as key sound, vibration prompts, etc., so that the operator can obtain the operation results in time and enhance the user experience.



5. Wireless connection stability: The gantry remote control device is controlled by wireless remote control technology, and the stability of its wireless connection is the most important. The design should consider the signal strength, anti-interference ability and other factors to ensure the stability and reliability of signal transmission.
