Portal Gantry Crane



Double girder Portal gantry crane is applied outside warehouse or railway sideways to do common lifting and unloading works. This kind of crane is composed of bridge, support legs, crane travelling organ, trolley, electric equipment,strong lifting winch. The frame adopts box-type welding mechanism. Crane travellilng mechanism adopts separate driver. All mechanisms are operated in the driver cabin. Power is supplied by cable or slide wire. There are different capacity double beams gantry crane for your choice according to your different use.



Double girder Portal gantry crane is a standard mobile gantry crane consist of a two legged A-frame support the trolley adopt flexible cable conductive, the gantry adopt slide wire or flexible cable conductive.



Double girder Portal gantry crane is ideal for outdoor applications where lifting facilities are provided, without the cost of a building or any supporting steelwork.



2. Parameters:



When purchasing a Portal gantry crane, please provide the following data so that we can confirm your needs faster!



① Lifting weight;



② Span (track center to guide rail center);



③ Lifting height (hook center grounded);



3. Component:



The gantry crane is mainly composed of the gantry, trolley, trolley operating mechanism, control room, electrical equipment and central rail device. The gantry crane's gantry consists of a main beam, left and right outriggers, and a cross beam. Compared with bridge cranes, the main feature of gantry cranes is that they are equipped with legs at one or both ends of the bridge, which can be directly supported on the foundation or run along tracks laid on the ground, so it is called a bridge with legs. type crane. Because the gantry crane can be equipped with a cantilever, it is convenient to lift and change cargo. It does not require a large and costly bridge pier, and the site area can be fully utilized. Therefore, in the cargo loading and unloading of cargo yards (railways, docks), gantry cranes are more suitable than Bridge cranes have many more advantages.



4. Applicable Environment:



Gantry cranes are widely used in open-air warehouses, freight yards, stations, docks, construction sites and other open-air places in various industrial and mining enterprises, transportation and construction construction departments for loading, unloading and transporting goods, equipment and installation of building components.



5. Feature of Double girder Portal gantry crane:



1.Safety First: Equipped with all moving limit switch, loading limit and other standard safety devices, to promise crane work safe.



2.Great Versatility: Grab bucket, container spreader and other lifting devices can be equipped.



3.Smooth Starting To Avoid Load Sway: Frequency conversion, double speed, single speed, and all hoisting and crane movements are independent, which can be run simultaneously different design duo to meet crane applications.



4.Competitive Quality and Price!!!



6. Maintenance of motors and reducers



To master the essence of crane component maintenance technology, you must first frequently check the temperature of the motor casing and bearings, and whether there are any abnormalities in the noise and vibration of the motor.



In the case of frequent starts, due to the low rotation speed, the ventilation and cooling capacity is reduced, and the current is large, the motor temperature rise will increase quickly, so it should be noted that the motor temperature rise must not exceed the upper limit specified in its instruction manual.



Adjust the brake according to the requirements of the motor instruction manual.



For daily maintenance of the reducer, please refer to the manufacturer's instruction manual. And the anchor bolts of the reducer should be checked frequently to ensure that the connection must not be loose.



7. Lubrication of running gear



Secondly, in the crane component maintenance technology, good ventilator lubrication should be remembered. If used, the vent cap of the reducer should be opened first to ensure good ventilation and reduce the internal pressure. Before work, check whether the lubricating oil level of the reducer meets the requirements. If it is lower than the normal oil level, add the same type of lubricating oil in time.



The bearings of each wheel of the traveling mechanism have been filled with enough grease (calcium-based grease) during assembly. Daily refueling is not required. Grease can be replenished every two months through the oil filling hole or the bearing cover. Every year Disassemble, clean and grease once.



Apply grease to each open gear mesh once a week.



8. Maintenance and maintenance of winch unit



Always observe the oil window of the crane reduction box to check whether the lubricating oil level is within the specified range. When it is lower than the specified oil level, the lubricating oil should be replenished in time.





When the crane is not used very frequently and the sealing condition and operating environment are good, the lubricating oil in the reduction gearbox should be replaced every six months. When the operating environment is harsh, it should be replaced every quarter.



When it is found that water has entered the crane box or there is always foam on the oil surface and it is determined that the oil has deteriorated, the oil should be changed immediately. When changing the oil, the oil should be replaced strictly according to the oil products specified in the reduction gearbox instruction manual. Do not mix the oil products.
