Gantry Jib

Single beam gantry jib



Single beam gantry jib is used with CD, MD and other types of electric hoist. It is a small and medium-sized crane with rail operation. Its applicable crane capacity is 3-32 tons, applicable span is 12-50 meters, and working environment is -20 ~ 40. ° C.



Single beam gantry jib is a general purpose crane ,open ground and storage to unload or grab materials,the bottom two forms of manipulation.The structure form of flower type,flower type,box type package.

2. Parameters:

Lifting Capacity(t)		3				5				10					16					20
Span(m) Customized		12	16	20	24	12	16	20	24	12	16	20	24	30	12	16	20	24	30	12	16	20	24	30
Lifting Height(m)		6/9				6/9				6/9					6/9					6/9
Travelling Speed(m/min)	Ground	20				20				20					20					20
	Controlling Room	20/30/45				20/30				20/30					20/30					20/30
Working Class		A3-A4
Electric Current		Three-phase AC 380V 50Hz

3. Component:



Electrical equipment, The operating motor used is in the form of a conical rotor motor, with electrical control, The electric hoist and the whole set of cranes are equipped with safety devices, such as lifting limit switch, end limit switch, etc.



4. Applicable Environment:

This machine is suitable for open-air fixed workshops in various fields, mines and enterprises. The same applicable environment as Single Girder Gantry Crane With winch Trolley.

5. Wearing Parts：

Rope guide, Carbon brusher



6. How to operate a Single beam gantry jib?



Customer customization



7. Transportation:

8. Safe features of Single beam gantry jib:



✔ Crane traveling limit switch



✔ Weight overload protection device



✔ Lifting height limit device



✔ Voltage lower protection function



✔ Phase sequence protection function



✔ Emergency stop function



✔ Rain cover for outside hoist, driving units, electrical cubicle.



✔ Warning indicator: flashing lights and warning sound.



✔ Wireless infra-detector for anti-collusion
