Caldwell Gantry Crane
Dejun caldwell gantry crane is a kind of crane between bridge crane and gantry crane, semi-gantry crane has only one leg, the other end of the crane is like bridge crane on the bearing beam of the plant, its lifting mechanism, trolley operating mechanism and bridge structure, and bridge crane is basically the same, rated weight is usually below 20 tons.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
1. Product Introduction:
Dejun caldwell gantry crane is a kind of crane between bridge crane and gantry crane, semi-gantry crane has only one leg, the other end of the crane is like bridge crane on the bearing beam of the plant, its lifting mechanism, trolley operating mechanism and bridge structure, and bridge crane is basically the same, rated weight is usually below 20 tons.
Compared with the Single Girder Semi Gantry Crane with Single Winch Trolley, when the electric hoist is used as the hoisting mechanism, the electric hoist runs along the track under the main beam; when the hoisting trolley is used as a hoisting mechanism, it runs on the main beam along the track on the main beam. The work level can reach A5-A6.
2. Parameters of caldwell gantry crane:
|
Span |
m |
10 |
12 |
16 |
20 |
|
Lifting Capacity(t) |
T |
5 |
10 |
15 |
Customized |
|
Lifting Height |
m |
6 |
6 |
6 |
6 |
|
Lifting Speed |
m/min |
8 |
8 |
8 |
8 |
|
Crane Speed |
m/min |
20 |
20 |
20 |
20 |
|
Trolley Motor |
kw |
0.4 |
0.4 |
0.4 |
0.4 |
|
Max Wheel Load |
KN |
14 |
19 |
27 |
35 |
|
Main Dimension |
mm |
10 |
12 |
16 |
20 |
|
Up Wheel Base |
W1 |
2000 |
2000 |
2500 |
3000 |
|
Hook Left Limitation |
S1 |
871 |
871 |
871 |
871 |
|
Up Leg Distance |
L1 |
1400 |
1400 |
1400 |
1400 |
3. Special design of caldwell gantry crane:
The box-shaped double beam welding structure increases the working space and is easy to transport, install and maintain.
The car adopts rail cable conduction device.
Parts standardization, serialization, generalization.
There are two kinds of cable winding type (left and right end) and sliding type (left and right end) for users to choose.
The cab has a wide field of vision, and the linkage console makes the operation flexible, balanced and comfortable. It can also be equipped with fans, hot air devices, chillers, air conditioners, intercom and so on.
4. Transportation of caldwell gantry crane:
5. Wearing Parts of caldwell gantry crane:
6. Frequently Asked Questions:
How long can we provide design solutions?
Less than 24 hours
Do you have engineer oversea installation service?
Yes; we have;
