Lightweight Electric Scissor Lift Platform

The scissor lift platform is a kind of vertical lift, which is widely used indoors and outdoors for special equipment for aerial work. It can be widely used for equipment maintenance, indoor and outdoor mechanical installation, equipment maintenance and building maintenance in stations, docks, bridges, halls, workshops.

It consists of multiple sets of booms mounted on a special self-propelled chassis, each set forming an X-shape. With the opening and closing of the scissor boom, the working bucket installed on the top of the uppermost boom group moves vertically.

All functions of the equipment are powered by a battery or an onboard diesel engine and controlled by a sealed hydraulic system, including safety protection brakes and critical hydraulic cylinder protection functions.

Operator-performable functions include: Lifting the platform, telescoping the platform, and manipulating the chassis (forward, reverse, steer).

2. Parameters:

3. Types of scissor lifts:

Scissor lift platforms are mainly divided into the following three types: traction lift platforms, mobile lift platforms and fixed lift platforms.

The traction lift platform adopts external power as traction, and uses three-phase power supply or diesel engine as power, which is convenient and fast to move and suitable for long-distance operations;

Mobile lifting platform is a wide range of special equipment for high-altitude work. Its scissor mechanical structure makes the lifting platform have high stability, wide working platform and high bearing capacity, so that the aerial work range is larger, and it is suitable for multiple people to work at the same time. It makes aerial work more efficient and safer.

The product structure of the fixed lifting platform is firm, the bearing capacity is large, the lifting is stable, the installation and maintenance of the lift are simple and convenient, and it is an economical and practical low-floor replacement for the elevator.

4. Component:

Scissor lift platform usually consists of three parts: platform, scissor lift mechanism and base. The platform is located on the top, mainly to bear the load, for the staff to carry out various high-altitude operations.

The scissor lift mechanism is a key component of the lifting platform. Different lifting platforms have their own scissor lifting mechanisms.

From low lift to high lift, the number of scissor rods increases, and the arrangement of hydraulic cylinders is also different. The number of arms of the scissor lift mechanism and the arrangement of hydraulic cylinders are determined by the lifting height.

The base is located at the bottom, and the legs, tires, fuel tank and other components are attached to it.

5. Applicable Environment:

The traction lift platform is mainly used for high-altitude operations in the fields of petroleum, electric power, urban construction, post and telecommunications and other industries.

Mobile lifting platforms are mainly used for indoor and outdoor mechanical installation, equipment maintenance and building maintenance in stations, wharfs, bridges, halls, and workshops.

The fixed lifting platform is a kind of cargo lifting equipment with good lifting stability and a wide range of applications.

It is mainly used for the transportation of goods between the height difference of the production line; the online and offline of materials; the adjustment of the workpiece height when the workpiece is assembled; the feeding of the feeder at a high place; the lifting of parts during the assembly of large equipment; the loading and unloading of large machine tools; warehousing loading and unloading The site is matched with forklifts and other handling vehicles for fast loading and unloading of goods.

6. Operating Specifications

(1) Only trained and qualified personnel can operate the lift.  

(2) Operators on the lift must wear seat belts.  

(3) Before the lift starts to operate, it is necessary to use the outriggers to level the chassis, and to firm the outriggers.  

(4) The operator must concentrate and operate according to the operation sequence specified in the instruction manual.  

(5) During the lifting and lowering process, the working table should be stable and flexible, and there should be no sudden jump or jamming phenomenon.

(6) If one of the following situations occurs in the hydraulic system, stop immediately for inspection, and take measures to eliminate it:  

① Abnormal noise; 

② The oil temperature rises rapidly; 

③ Abnormal cylinder pressure and oil return pressure; 

④ Oil leakage in the oil circuit; 

⑤ When pressing the "Up" or "Down" button, or after pushing the "Up" or "Down" manual valve, the workbench does not move.  

(7) After pressing the "up" or "down" button, if the worktable does not move, in addition to checking the hydraulic system, check whether the lifting mechanism is stuck, whether the electrical part is disconnected, and whether it is overloaded. .  

(8) There should be a safety clearance above the workbench

(9) If the power supply is disconnected before turning on the power supply or during the lifting and lowering of the worktable, the operator must pay attention to make all the controllers at the zero position.  

(10) When the operator is working at heights, the operator shall not operate the lift at will.  

(11) During the lifting and lowering of the workbench, no part of the body of the person on the workbench shall exceed the limit of the workbench.  

(12) When the operator leaves the elevator, he must cut off the lifting power source.

7. Transportation:
