Kenya Double Girder Semi Gantry Crane Project
Apr 22, 2025
As an important lifting machine, the double girder semi gantry crane is widely used in various industrial fields. Therefore, our semi gantry crane is hot selling in the lifting machine market. Currently, a Kenyan client ordered a double girder semi gantry crane with a lift weight of 70 tons. The lift weight depends on your application needs. We will select a suitable crane machine according to your requirements. Before the order, our engineers will draft a drawing for you, and you can visit our factory in person. This Kenyan client mainly uses the semi gantry crane in their factory to carry heavy objects. By knowing their factory areas and using frequency, we recommended that they buy a 70-ton semi-gantry crane. And now, the crane machine has been shipped to Kenya. For more details about this order, please keep reading!
Semi Gantry Crane For Sale
Semi Gantry Crane To Kenya
70 ton Semi Gantry Crane Specification
|
Item
|
Double Girder Semi Gantry Crane
|
|
Lifting capacity
|
70ton
|
|
Span
|
9.5175M
|
|
Lifting height
|
14m
|
|
Lifting speed
|
0.4-2.4m/min
|
|
Trolley speed
|
5-20m/min
|
|
Crane speed
|
10m/min
|
|
Hoist lifting power
|
38KW
|
|
Trolley lifting power
|
3*2KW
|
|
Crane power
|
2.2*4KW
|
|
Total power
|
52.8KW
|
|
Hoist lifting rotation speed
|
2250n/min
|
|
Hoist insulation class
|
H
|
|
Hoist protection class
|
IP54
|
|
Hoist drum diameter
|
405mm
|
|
Working class
|
A5
|
|
Trolley insulation class
|
H
|
|
Trolley protection class
|
IP55
|
|
Wheel diameter
|
400mm
|
|
Crane rotation speed
|
1380n/min
|
|
Operating temperature
|
-20℃ ~ +40℃
|
|
Payment term
|
TT
|
|
Brand
|
What Is the Semi Gantry Crane?
The double girder semi-gantry crane is a special type of lifting equipment. Its structural feature is that it has outriggers on one side but no outriggers on the other. Specifically, one end of the semi-gantry double-girder crane's outriggers is directly supported on the track, while the other end is supported on the ground track through the outriggers, forming a semi-gantry appearance. Due to its single-leg design, this type of crane can effectively save working space and is particularly suitable for use in environments with limited space. It is widely used in various indoor and outdoor lifting tasks, such as mechanical workshops, warehouses, and freight yards etc. In addition, compared with traditional bridge cranes, semi-gantry double-girder cranes require fewer support columns, thus saving a significant amount of costs.
Single Girder Semi Gantry Crane
Double Girder Semi Gantry Crane
What are the parts of a semi gantry crane?
The double-girder semi-gantry crane is mainly composed of the frame, the cantilever beam, the trolley, the hoist, the lifting mechanism, and the electrical control system.
-
Frame: The frame is the foundation of the double girder semi-gantry crane, usually built on the ground, and supports the entire weight and load of the crane through its support. The frame is generally made of a steel structure and has sufficient strength and stability.
-
Cantilever beam: The cantilever beam is the core part of the double-girder semi-gantry crane, extending into the working area to support the lifting mechanism and the load. The structure of the cantilever beam is usually divided into truss structure and beam plate structure, which can be selected according to the needs of the lifting task.
-
Trolley and hoist: The trolley is responsible for moving the load from one position to another, usually composed of a motor, a reducer, wheels and a brake, etc. The hoist is responsible for moving the lifting mechanism on the trolley to the correct position to lift and lower the load.
-
Lifting mechanism: The lifting mechanism is the key part of the double-girder semi-gantry crane, responsible for lifting and lowering the load. It is composed of an electric motor, a reducer, a drum, a wire rope, etc., and can achieve smooth lifting and lowering of the load.
-
Electrical control system: The electrical control system is responsible for controlling the movements of the crane, including the trolley, the hoist and the lifting mechanism. Through the electrical control system, the crane can achieve automation and precise control.
Where To buy It?
Regarding the gantry crane supplier, various Chinese manufacturers are for your reference. But the Dejun Company is a reasonable choice for you. Dejun Company is a leading manufacturer and exporter of lifting machines in China. Semi gantry cranes are our main products, we have advanced gantry crane production lines at our factory. You can visit our factory in person before you place an order. Moreover, we can customize the machine according to your needs. Therefore, you should send us your requirements first, and then we will send you the price! Besides the semi gantry crane, we also produce and sell portable gantry cranes, overhead cranes, jib cranes, and electric hoists, etc.
Semi Gantry Crane Production
Semi Gantry Crane Delivery
Conclusion
In conclusion, the double-girder semi-gantry crane plays a significant role in the industrial field due to its advantages, such as simple structure, large lifting capacity, wide application range, and safety and reliability. At present, the double girder semi gantry crane has been shipped to Kenya. Any question about this order, please feel free to contact us!
